• AC Output Voltage: Grid-Tie: 120/208, 30 VAC
• Maximum AC Power Output: Backup: 7,600 W
• AC Output Voltage: Backup: 120/208, 10 VAC
• AC Circuit Breaker: Backup: 50 A
• DC Input Voltage Range: 360 - 420 VDC
• Nominal DC Bus Voltage: 380 VDC
• Supported Battery Types: PWRcell Battery
• Batteries Per Inverter: Up to 2
• Supported PV Optimizers: PV Link
• Maximum Recommended DC Power from PV: 15 kW
• Internal DC Distribution Breakers: 4x 2P30A
• DC Fuses on Plus and Minus: 40 A
• 2-Pole Disconnect: Yes
• Protections: Ground-Fault Isolation Detection, Reverse-Polarity
• AC Topology: Transformerless
• Peak Efficiency: 97.3%
• CEC Weighted Efficiency: 97%
• Operating Temperature: -20 to 50 C (-4 to 122 F)
• Dimensions: 622 x 489 x 203 mm (24.5" x 19.25" x 8")
• Compliance: UL 1741 SA, CSA 22.2, IEEE 1547, Rule 21
• Compliance (Cont.): Rule 14H
• Peak Motor Starting Current (2 Sec.): 50 A, RMS
• Max. Cont. Grid-Tied AC Power @ 122 F (50C) : 11,400 W
