Features - Programmable Low Voltage Shutdown
- Overload Protected
- Short Circuit Protected
- Built-in GFCI
- DSP Controlled
- Programmable Frequency
- Over Temperature Protected
- Programmable Output Voltage
- Five year parts and labour warranty
- Product Datasheet | Download
- Product Manual | Download
Digital Signal Processor controlled high power MOSFET technology creates a low voltage sine wave that is fed into a compact toroidal step-up transformer to create a very clean low EMI AC output.
Using the free to download "Inverter Wizard" software, the user can select output frequency, output voltage, and low voltage shutdown parameters from any Windows laptop through the standard micro-usb interface as well as monitoring and logging input and output voltages, output power and inverter temperature.
Safety features include current limiting, short circuit protection, overtemperature warning and shutdown and low input voltage warning and shutdown (user adjustable).
An Off-Line UPS options allows external AC to be routed through the inverter to the load. The inverter will take over supplying the load only if the external AC fails.
| Function | Inverter |
|---|
| Conversion | DC to AC |
|---|
| Power Level | 360 |
|---|
| Input Volts | 10.5 - 18 VDC |
|---|
| Output Volts | 110 VAC |
|---|
| Output Amps Continuous | 3 |
|---|
| Output Amps Peak | 3.6 |
|---|
| Input/Output Isolation | Yes |
|---|
| Technology | Digital |
|---|
| Product Series on website | IPSi365 |
|---|
| Option Codes | 'Z' No Conformal Coating (Any Model), 'X' Ruggedized & Wide Temp, 'U' Safety Special Inspection (CSA/UL), 'M' Military Rugged, 'A' AC Detect & Autoswitch (Off Line UPS) |
|---|
