Manufacturer Info
Features
- All AC and DC buses installed and fully pre-wired
- Label backlighting pre-installed
- ON - indicating LEDs installed in all circuit positions
- 100 Ampere C-Series Toggle Circuit Breaker provides main circuit protection and switching for DC branch
- Cutout Templates
- Cutout Template
Specifications | |
---|---|
Positions | 8 AC29 DC |
Nominal Voltage | 120V AC12V DC |
Height | 11.50in (292.1 mm) |
Width | 19.50in (495.3 mm) |
Depth | 3.00in (76.2 mm) |
Weight | 12.45lb (5.65 kg) |
Included | ||
---|---|---|
Qty | PN | Product |
5 | 7210 | A-Series White Toggle Circuit Breaker - Single Pole 15A (AC Branch) |
1 | 7238 | A-Series White Toggle Circuit Breaker - Double Pole 30A (AC Main) |
1 | 9353 | AC Voltmeter - 0 to 150V AC (AC Meter) |
1 | 9630 | AC Ammeter - 0 to 50A with Coil (AC Meter) |
20 | 7210 | A-Series White Toggle Circuit Breaker - Single Pole 15A (DC Branch) |
1 | 7250 | C-Series White Toggle Circuit Breaker - Single Pole 100 Amp (DC Main) |
1 | DC Analog Voltmeter - 8 to 16V DC (DC Meter) | |
1 | 8017 | DC Analog Ammeter - 0 to 100A with Shunt (DC Meter) |
