Features - Listed to UL 458 Standards
- 1000 watt low frequency inverter
- 3000 watt surge for 20 seconds -3x surge capability
- Battery Priority Selector
- Terminal Block
- GFCI
- Marine Coated and Protected
- Multi Stage Smart charger 35 Amp
- remote panel available
- auto gen start
- auto frequency
- 10msec typical transfer time
- 7 battery type settings for charger
- Product Manual | Download
Inverter Output Specifications - Listed to UL 458 Standards
- Continuous Output Power: 1000 Watts
- Surge Rating: 3000 Watts (20 Seconds)
- Output Waveform: Pure Sine/Same as input (Bypass Mode)
- Output Voltage: 100-110-120Vac
- Nominal Efficiency: >92% (Peak)
- Line Mode Efficiency: >95%
- Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
- Typical Transfer Time: 10ms (Max)
- THD: < 10% DC
Input Specifications - Nominal Input Voltage: 12.0Vdc
- Minimum Start Voltage: 10.0Vdc
- Low Battery Alarm: 10.5Vdc-11.0Vdc
- Low battery Trip: 10.0Vdc-10.5Vdc
- High Voltage Alarm: 16.0Vdc
- Low battery Voltage Restart: 13.0Vdc
- Idle Consumption: 12.5 watts
- Power Saver Mode Idle Consumption: 7.5 watts
Charger Specifications - Output voltage: Depends on battery Type
- Charger Rate: 35A
Dimensions - Unit Weight: 36.5 lbs.
- Unit Size L x W x H: 15.35 x 11 x 7 inches
- Shipping Weight: 44 lbs.
- Shipping L x W x H: 20.5 X 13.8 X 12.2 inches
