The images shown are for illustration purposes only and may not be an exact representation of the product

Analytic Systems, BCD615-48-24, 20A, 24V Out, 40-60V In, Iso DC/DC Battery Charger, 2 Bank

  • Model: BCD615-48-24
  • Manufactured by: Analytic Systems
  • Condition: New
  • Estimated Delivery: 2 to 3 Weeks
  • Built to Order - This Product Cannot Be Cancelled Once Order Is Placed

$1,656.72 $1,274.40

Manufacturer Info

  • Power from 300 to 1500 watts
  • Isolated DC DC Charger
  • Output from 12 to 72 VDC
  • Input volts from 12 to 400 VDC
  • Three year warranty (parts & labor)
  • Product Datasheet | Download
  • Product Manual | Download
Isolated BCD series chargers feature precision charging voltages for 1, 2 or 3 banks of batteries at 12, 24, 32, 36, 48 or 72(rail) volts DC. Models are available to operate from input voltages as low as 10 VDC and up to 400 VDC at power levels from 300 to 1500 watts.

All models feature user selectable 2-stage or 3-stage charging profiles, temperature compensation and user initiated battery equalization for optimum charging and maximum battery life. Full isolation allows different ground levels to be accommodated (i.e. Charging a positive ground battery from a negative ground source or vice-versa).
FunctionBattery Charger
ConversionDC to DC
Power Level600
Input Volts40 - 60 VDC
Output Volts24 VDC
Output Amps Continuous22
Input/Output IsolationYes
Charging Stages3
Temperature CompensationYes
Battery Banks2
Product Series on websiteBCD615
Option Codes'Z' No Conformal Coating (Any Model), 'X' Ruggedized & Wide Temp, 'V' Digital Volt/Ammeter, 'U' Safety Special Inspection (CSA/UL), 'R' 19 Inch Rackmount, 'Q' 23 Inch Rackmount, 'O' Open Frame - No chassis, 'M' Military Rugged, 'J' MIL810 Tested Only, 'I' MIL461 Tested Only, 'G' GMDSS (DVAM & RCP1 Remote), 'E' European ROHS compliant, 'C' MIL461F & MIL810G Tested
