MasterVolt 81500300 DC Master 24/12-12A (Isolated)

Security Seals
  • Model: 81500300
  • Manufactured by: Mastervolt
  • Condition: New
  • Estimated Delivery: May 23rd - May 29th
  • In Stock
  • Price: $209.12  $167.30
    Save: 20% off
    • Recreational and semi-professional use.
    • Easy to install using included mounting bracket screws and fasteners.
    • Smart electronics mean no unnecessary heat generation.
    • Continuous output.
    • Insulated and non-insulated models available.
    • Two minutes of extra power for short power boosts.
    • Excellent price/performance ratio.
    • Product Specifications | Download
    Always on course with Mastervolt

    Mastervolt ensures you an electrical system with no weak links and a dependable and silent power supply. Whether for recreational or professional purposes with Mastervolt you always have power you can rely on... The power to be independent.

    DC Master DC-DC converters

    The required voltage for DC current can vary. Some equipment requires 24 V while onboard equipment usually requires 12 V. For custom DC current Mastervolt offers a series of compact and made to measure DC-DC converters for both 12 V and 24 V battery systems that offer stable power with the right current for any connected consumer. There is a wide range of DC Master converters available including insulated and non-insulated models.
    General specificationsGeneral specifications
    Nom. output voltage13.6 V
    Max. output power245 W
    Nom. output power164 W
    Max. output current (for 2 min. intervals)18 A
    Cont. output current12 A
    Nominal input voltage24 V
    Input voltage range20-32 V
    Galvanic isolationyes
    Dimensions hxwxd167 x 87 x 50 mm 6.6 x 3.4 x 2.0 inch
    Weight0.59 kg 1.3 lb
    ApprovalsCE E-mark
    Technical specificationsTechnical specifications
    DC consumption< 10 mA
    Temperature range (ambient temp.)-25 C to 80 C derating > 30 C -13 to 176 F
    Coolingnatural cooling
    Sound level< 30 dBA at 1 mtr
    Protection degreeIP53
