Analytic Systems, VTC120h-48-12, 7.5A, 12V Out, 44-60V In, Iso DC/DC Converter
The images shown are for illustration purposes only and may not be an exact representation of the product

Analytic Systems, VTC120h-48-12, 7.5A, 12V Out, 44-60V In, Iso DC/DC Converter

  • Model: VTC120h-48-12
  • Manufactured by: Analytic Systems
  • Condition: New
  • Estimated Delivery: 2 to 3 Weeks
  • Built to Order - This Product Cannot Be Cancelled Once Order Is Placed
  • Price: $619.52  $476.55
    • Ultra-quiet
    • Power sensitive electronics without interference
    • Rugged and reliable to ensure years of safe and trouble free operation
    • Versatile design with wide variation of input and output combinations
    • Precision linear regulator final stage for ultra clean output for all units (except VTC120nr-12-24)
    • Extremely rugged and well suited for marine and other demanding environments
    • High tolerance for shock and vibration
    • Ultra-quiet low EMI operation
    • Ideal for running 24V PLC controls from 12 VDC
    • Reverse input protection
    • Short circuit protection
    • Three year parts and labour warranty
    • VTC120ih Series Datasheet | Download
    • VTC120ih Series Manual | Download
    The VTC120i Series of Isolated Voltage Converters are variable duty cycle switching power supplies with precision linear regulator outputs. They can be configured to run from a 12V, 24V or 48VDC battery system to provide input/output voltages as shown below.

    Applications include running 24V PLC controls from a 12 Volt battery system, or any other application requiring 24 VDC when only 12 VDC is available or to provide ground isolation between two 12 VDC or 24 VDC power systems, or between a 12 VDC and 24 VDC power system.
    Function Voltage Converter
    Conversion DC to DC
    Power Level 120
    Input Volts 44 - 60 VDC
    Output Volts 12 VDC
    Output Amps Continuous 7.5
    Output Amps Peak 7.5
    Input/Output Isolation Yes
    Technology Analog
    Product Series on website VTC120
    Option Codes 'Z' No Conformal Coating (Any Model), 'X' Ruggedized & Wide Temp, 'U' Safety Special Inspection (CSA/UL), 'O' Open Frame - No chassis, 'M' Military Rugged, 'J' MIL810 Tested Only, 'I' MIL461 Tested Only, 'H' High Output, 'F' Electric Fork Lift, 'E' European ROHS compliant, 'C' MIL461F & MIL810G Tested
    More Options Linear Post Regulator
