Analytic Systems, VTC120-48-24, 5/5.5A, 24V Out, 44-60V In, Iso DC/DC Converter
Manufacturer Info
Features
Applications include running 24V PLC controls from a 12 Volt battery system, or any other application requiring 24 VDC when only 12 VDC is available or to provide ground isolation between two 12 VDC or 24 VDC power systems, or between a 12 VDC and 24 VDC power system.
- Ultra-quiet
- Power sensitive electronics without interference
- Rugged and reliable to ensure years of safe and trouble free operation
- Versatile design with wide variation of input and output combinations
- Precision linear regulator final stage for ultra clean output for all units (except VTC120nr-12-24)
- Extremely rugged and well suited for marine and other demanding environments
- High tolerance for shock and vibration
- Ultra-quiet low EMI operation
- Ideal for running 24V PLC controls from 12 VDC
- Reverse input protection
- Short circuit protection
- Three year parts and labour warranty
- Product Manual | Download
Applications include running 24V PLC controls from a 12 Volt battery system, or any other application requiring 24 VDC when only 12 VDC is available or to provide ground isolation between two 12 VDC or 24 VDC power systems, or between a 12 VDC and 24 VDC power system.
Function | Voltage Converter |
---|---|
Conversion | DC to DC |
Power Level | 120 |
Input Volts | 44 - 60 VDC |
Output Volts | 24 VDC |
Output Amps Continuous | 5 |
Input/Output Isolation | Yes |
Technology | Analog |
Product Series on website | VTC120 |
Option Codes | 'Z' No Conformal Coating (Any Model), 'X' Ruggedized & Wide Temp, 'U' Safety Special Inspection (CSA/UL), 'O' Open Frame - No chassis, 'M' Military Rugged, 'J' MIL810 Tested Only, 'I' MIL461 Tested Only, 'F' Electric Fork Lift, 'E' European ROHS compliant, 'C' MIL461F & MIL810G Tested |
