The images shown are for illustration purposes only and may not be an exact representation of the product
Get Optimal Performance From Your PV Panels and Batteries
- Maintenance-free protection for your batteries and solar panels
- Regulated output to prevent batteries from overcharging
- Load Disconnect protects batteries from being over-discharged
Features and Benefits - Handles up to 30A Amps of Array Current or up to 450 Watts of solar power
- Protects battery from overcharge and discharge
- Maintains 12V batteries in a fully charged state
- LED status indicator provides quick reference to Battery and load status (SC models)
- LED digital display shows charging current, loads current and battery voltage (SCD model)
- Temperature compensation
- 2 Year warranty
- Product Specifications | Download
- Product Manual | Download
| Solar Charge Controller | SC1220LD |
|---|
| DC Input (PV) |
|---|
| Max. PV Voltage | 26V |
|---|
| Max. PV Current | 20A |
|---|
| Voltage across PV & Battery | < 0.15V |
|---|
| DC Output (Battery) |
|---|
| Battery Rating |
|---|
| Battery Type | Sealed/Flooded |
|---|
| Max. Charge Current | 20A |
|---|
| Charge Voltage Range | 14.2 - 14.6V |
|---|
| Float Voltage Range | 13.4 - 13.8V |
|---|
| Parasitic Current | <15mA |
|---|
| DC Output (Load) |
|---|
| Load Current (Continuous) | 20A |
|---|
| Protection |
|---|
| PV Reverse Polarity | Protected |
|---|
| Battery Overcharge | Yes |
|---|
| Load Over-discharge Voltage | < 11.5V |
|---|
| Load Reconnected Voltage | 12.6V |
|---|
| Enclosure |
|---|
| Input/Output Connection | Heavy duty terminals |
|---|
| Weight | 5.7 lbs |
|---|
| Dimension | 11.6 x 8.1 x 3.4" |
|---|
