This modular 19 rack mount AC/DC power supply can provide up-to 50 Amps continuous power. The output DC voltage is highly regulated at 27.6 Volts (120 Volts AC input). An external battery can be connected for back-up and a section of the output current (up-to 8 amps) is diverted to charge the batteries when in state of discharge using the in-built battery back-up module. The battery supplies the DC load on loss of utility power. Features include N+1 redundancy front panel analog Volt/Ampere meter display remote monitoring and indication by 25-pin D-sub connector fan failure warning and alarm indication. Ideal for critical power supply applications telecommunication systems mobile sound/audio displays GPS receivers security systems CCTV systems.
Design Features- Provides N + 1 redundancy
- Voltage/Ampere meter
- Module status LEDs, fault indicator LEDs and fault alarm are standard features on all models
- Highly regulated output voltage
- Short circuit protection and overload current
- Product Specifications | Download
- Product Manual | Download
Applications- Any critical power supply application
- Telecommunications systems
- Mobile sound/audio displays
- GPS receivers
- Security systems
- CCTV systems
| Input | 120 VAC |
| Output | 27.6VDC |
| Amps | 50 Amps |
| Weight | 25 (lbs) |
| Weight | 11.33 (kgs) |
| Dimensions | 19 x 16.25 x 3.5 (in) |
| Dimensions | 48.3 x 41.3 x 8.9 (cm) |
| Warranty | 2 years (Canada/US) |
