Cotek, AD1500-400 A24, Parallel, RS485 and Meet PMBus Programmable Power Supply

The images shown are for illustration purposes only and may not be an exact representation of the product

Cotek, AD1500-400 A24, Parallel, RS485 and Meet PMBus Programmable Power Supply

Model: AD1500-400 A24
Manufactured by: Cotek
Condition: New
Estimated Delivery: Oct 25th - Oct 31st
In Stock
Out of Stock

Price:

$969.80 $746.00

Manufacturer Info

Other products

AD-1500-HV

AD-1500-HV Features

Universal AC input (90-264Vac).
Programmable output voltage & current 0~105%.
Optional Changeable interface cards: A23, A24, C11, and Ethernet.
Built-in ORingFET and communication isolation circuit.
Support Parallel operation via CANBUS.
Built-in communication isolation circuit. (A23, A24 Version)
Constant current limit.
Auxiliary output support 5V/1A.
PMBus, MODBUS, RS232/485, and I2C protocol supported.
Protection: OVP, OLP, OTP, UTP, AC Failure, Power and Fan Failures.
Intelligent GUI to set and monitor parameters.
Accessory: AD COMMS Interface Kits. (Optional)
Datasheet | Download

MODEL	AD-1500-120, AD-1500-150, AD-1500-250, AD-1500-400
Main Features	? Variety of protocols supported: PMBus, MODBUS, RS232/485, and I2C ? Smart GUI to set and monitoring the power supplies remotely
Rated Power	1500W
DC Output Voltage	120V; 150V; 250V; 400V
DC Output Quantity	Single
Rated Current	12.5A; 10.0A; 6.0A; 3.75A
Ripple & Noise (Max.)	1200mVp-p (120V)
Input Voltage Range	90 ~ 264VAC, 250~370VDC
Inrush Current (Typ.)	30A / 115VAC, 45A / 230VAC (cold start)
Function	Auxiliary power; Remote ON/OFF control; Power OK signal; Output voltage and current trim (C11 only)
Parallel Connection	Yes
Protection	Over Load / Over Voltage / Over Temperature / Short Circuit / Fan Failure
Cooling	Load and temperature control fan
Efficiency	92%
Operating Temperature	-25~60?
Storage Temp. & Humidity	-40~85?, 10~95%RH
Safety	TUV / UL / CE / UKCA / CB
Dimension (WxHxD)	127.8x64x296.3 mm / 5.03x2.52x11.67 inch
Weight (Net)	2.21kg
