Solar Charge Controller Waterproof 11 Amps with CablesSuper easy to install, waterproof solar charge controller. The controller includes the solar panel and battery cables for quick set up. Compact, but powerful measuring at only
Features - Easy to install
- Waterproof - IP68
- Built in cables for easy extension using the MC4 connectors
- LED indicators
- 2 stage charger
- AIMS Power 11 amp waterproof charge controller - SCC11APRM | Download
Specifications - 12V battery systems
- Max charge current - 11A
- Max PV input voltage - <30Voc
- Max PV Input Power - 190W (depending on sunlight)
- Boost charge - 14.2V
- Float charge - 13.8V
- Boost charge recovery voltage - 13.2V
- Over discharge recovery voltage - 11.1V
- PV input cable length - 13 inches
- Battery output cable length - 5 FT
- Boost charge duration - 2 hours
- Operating temp -32F to 140F / -35C to 60C
- IP68
- Weight - .5 lb unit, 1 lb shipped
- Dimensions - 3.25" X 1.75" x .625"
