N Series Inverter, 48 Volt 48IX10NV
Inverters & Chargers

The N Series Inverter is a low frequency, pure sine wave inverter line made for handling loads in work and utility trucks. The series is available from 400 watts to 5600 watts and in 12, 24, or 48 VDC models, giving you choices to fit your needs.

The N Series Inverter model utilizes an iron-core transformer that can handle the frequent power surges associated with industrial-grade tools, pumps, heaters, and motors. The 48IX10NV also has a ventless chassis for moisture and dust protection.

Features

• Engineered construction and cooling methods
• Thermally controlled cooling fan
• Enclosed AC and DC cable connections
• Remote ON/OFF switch hookup
• GFCI outlet protection
• LED indication of external power, inverter power, low input voltage, high temperature, and overload
• Automatic electronic short circuit/overload protection
• Automatic over temperature shutdown
• Output circuit breakers
• Automatic low battery shutdown with in-rush delay
• N Series 48volt datasheet | Download

The N Series Inverter is also available in 12 volt and 24 volt configurations.

Industries

• Emergency Medical Services
• Marine Systems
• Military Vehicles
• RV Systems
• Trucks
• Utility Vehicles

48IX10NV
Output Power	1000 watts
Peak Watts	2500 watts
Output Voltage	120 VAC 5%
Peak Output Current	55 AAC
Output Current	8 AAC
Output Waveform	Pure Sine
Output Frequency	60 Hz 0.5 Hz
Motor Starting Capacity	1/2 hp
Input Voltage	48 VDC
Continuous Output Amps	8 amps
Efficiency	Up to 87%
Phase	Single
Topology	Low Frequency
Warranty	Two years

48IX10NV
Weight	33 lb [15 kg]
Dimensions	15.4” x 8.3” x 7.6” [39.1 x 21.1 x 19.3cm]
Operating Temperature	-20 to 60C [0 to 140F]
