Blue Sea Systems, 5511e, e-Series Dual Circuit Plus Battery Switch
Blue Sea Systems, 5511e, e-Series Dual Circuit Plus Battery Switch
×
6 Additional Images
The images shown are for illustration purposes only and may not be an exact representation of the product
Blue Sea Systems, 5511e, e-Series Dual Circuit Plus Battery Switch
Model:
5511e
GTIN:
00632085551155
Manufactured by:
Blue Sea Systems
Condition:
New
Estimated Delivery:
May 3rd - May 9th
Estimated Delivery:
1 to 2 Weeks
In Stock
Out of Stock
Lead Time To Ship May Vary
Price:
$106.62
$82.01
Add to Cart
Manufacturer Info
Other products
Simultaneously switches two isolated battery banks or combines battery banks to all loads
Make-before-break contact design allows switching without power interruption
Ignition protected - safe for installation aboard gasoline powered boats
Case design allows surface or rear panel mounting
Instructions |
Download
Mouting Diagram |
Download
Specifications
Switch Type
Dual Circuit Plus
Color
Red
Switch Positions
3
Battery Combine
Yes
Alternator Field Disconnect
No
Maximum Voltage
32V DC
Terminal Stud Torque
140 in-lb (15.82 Nm)
Continuous Rating
350A
Intermittent Rating
525A (5 min)
Cranking Rating 30 sec
700A per circuit
Battery Inputs
2
Cable Clearance For 4/0 AWG Cables
1.10in (27.94 mm)
Cable Size to Meet Ratings
4/0 AWG (120mm²)
Mounting Holes
Accept 1/4" (M6) Screw
Stud Material
Tinned Copper
Terminal Stud Size
3/8" - 16 (M10)
Weight
1.16lb (0.53 kg)
Weight
1.30lb (0.59 kg)
Optional Accessories
7902
Battery Switch ICON Label Kit
Works With
7608
20A BatteryLink® Charger (North America)
7607
20A BatteryLink® Charger (Europe)
7606
20A BatteryLink® Charger - Bare Wire (Universal)
Included With
8690
Dual Battery Bank Management Panel
8693
Triple Battery Bank Management Panel
7650
Add-A-Battery Kit - 120A
7650003
Add-A-Battery Kit - 120A [Boxed]
