Electrical |
Peak Efficiency | 97.50% |
Nominal Battery Voltage | 12 or 24 volts |
Max. Battery Current | 15 amps |
Battery Voltage Range | 7-36 volts |
Max. PV Open Circuit Voltage | 75 volts |
Nominal Max. PV Input | 12 volt battery 200 Watts 24 volt battery 400 Watts |
Output Rating | 15 amps load control |
Self Consumption | 35 milliamps |
Transient Surge Protection | 4 x 1500 Watts |
Environmental |
Operating Temperature | –40C to +60C |
Storage Temperature | –55C to +100C |
Humidity | 100% non-condensing |
Tropicalization | Epoxy encapsulation Conformal coating Marine rated terminals |
Electronic Protections |
PV: | Overload, Short Circuit, High Voltage |
Load: | Overload, Short Circuit |
Reverse Polarity: | Battery, PV and Load |
| Lightning and Transient Surges |
| High Temperature |
| Reverse Current at Night |
Battery Charging |
Battery Types | Gel, Sealed, AGM, Flooded |
4 Stage Charging | Bulk, absorption, float, equalize (optional) |
Temperature Compensation |
Coefficient | –5mV/C / cell (25C ref) |
Range | –30C to +60C |
Set points | Absorption, float, equalize |
Mechanical |
Dimensions | 16.9 x 6.4 x 7.3 cm 6.6 x 2.5 x 2.9 inch |
Weight | 0.60 kg / 1.3 lbs |
Power Terminal | 16 mm2 / #6 AWG |
Enclosure | Die cast aluminum with plastic cover |
Options | Remote Meter, Remote Temperature Sensor, PC MeterBus Adapter, DIN Rail Mounting Clips |
|
Certifications | CE Compliant, RoHS Compliant, Manufactured in a certified ISO 9001 facility |
