Victron Energy, VEP230121402, VE Panel 3kVA 120/240 NA Primary 24/48Vdc

  • Model: VEP230121402
  • GTIN: 08719076053842
  • Manufactured by: Victron Energy
  • Condition: New
  • Estimated Delivery: 6 to 8 Days
  • Lead Time To Ship May Vary

$1,215.50 $935.00

Manufacturer Info

  • Internally pre-wired enclosure.
  • A built-in AC bypass switch with full system current capability, and a DC disconnect breaker for safe and easy isolation for servicing of the inverter and/or battery bank.
  • Battery to inverter/charger DC disconnect breaker (250 Amps).
  • Inverter AC input overcurrent protection breakers.
  • DIN mount AC and DC breakers for quick and easy operation.
  • A500A/50mV DC shunt installed for easy connection to battery status monitor.
  • Enclosure and components are UL/CSA certified and designated for indoor use.
  • Configurations available for both single 120 and 230 VAC, 120/240 VAC and 3-Phase systems.
  • DC negative, positive and ground busbars for DC loads and PV arrays included.
  • Mounting provided for DIN rail DC load/disconnect breakers.
  • Integrates directly with Victron Energy’s 3,000 and 5,000 MultiPlus and Quattro inverter/chargers.
  • Knockouts for inverter/charger and battery cables, PV in/out, DC panel mount breakers.
  • Victron Electrical Panel Installation and Service Manual | Download
  • The VE Panel (VEP) is designed for the 3kVA and 5kVA MultiPlus and Quattro inverter/chargers.
Description Part Number
VE Panel 3kVA 120/240 NA Primary 24/48Vdc VEP230121402
VE Panel 3kVA 120 NA Follower 24/48Vdc VEP230141204
VE Panel 3kVA NA 3PH Primary 24/48Vdc VEP230161604
VE Panel 3kVA 230 Export Primary 24/48Vdc VEP230422002
VE Panel 3kVA 230 Export Follower 24/48Vdc VEP230442004
VE Panel 3kVA 230 Export 3PH 24/48Vdc VEP230462206
VE Panel 5kVA 120/240 NA Primary 48Vdc VEP250125402
VE Panel 5kVA 120 NA Follower 48Vdc VEP250145204
VE Panel 5kVA NA 3PH Primary 48Vdc VEP250165606
VE Panel 5kVA 230 Export Primary 48Vdc VEP250426002
VE Panel 5kVA 230 Export Follower 48Vdc VEP250446004
VE Panel 5kVA 230 Export 3PH 48Vdc VEP250466206
