DPDT 40 A Relays

These double-pole, double-throw (DPDT) relays are rated at up to 40 A at 12, 24, or 48 VDC or 120 or 240 VAC. All contact surfaces are silver alloy with gold flashing. Contact terminals are #8-32 screws, and coil terminals are #6-32 screws. Relays with 120 VAC or 240 VAC coils can be used to build simple transfer switches. Relays with DC coils can be used for remote operation of pumps and fans. By connecting a relay with a DC coil to a voltage-controlled switch, AC or DC loads may be turned on or off based on battery voltage levels.

OutBack 16 A 30 VDC/250 VAC DIN-Mount Relays

The 12 VDC coil DIN rail mount DPDT relay can be used to activate a two-wire start generator, or other functions, when wired to the 12 VDC AUX output of many inverters or charge controls, including OutBack Radian or FX Inverters, OutBack Charge Controls, MidNite charge controls, and Schneider XW inverters and chargers. It draws a small 34 mA coil current.

The 24 VDC coil version of this relay can be used in conjunction with a 24 VDC circuit for the FireRaptor module level rapid shutdown devices to close a contact in an FM100-AFCI charge control, or other devices.

Omron SPST 10 A Relay

This enclosed surface-mount single-pole, single-throw (SPST) relay has one set of contacts that closes when power is applied to the coil terminals. It can be used with an inverter or charge controller's 12 VDC auxiliary output to provide a contact closure for generator start or other controls. The terminals are quick connect. It draws a small 44 mA coil current.
