Blue Sea Systems
Blue Sea Manual Battery Switches
Blue Sea Systems, 3003, HD-Series Heavy Duty Selector Battery Switch with AFD
Blue Sea Systems, 3003, HD-Series Heavy Duty Selector Battery Switch with AFD
Model:
3003
GTIN:
00632085030032
Manufactured by:
Blue Sea Systems
Condition:
New
Estimated Delivery:
1 to 2 Weeks
Estimated Delivery:
May 23rd - May 29th
In Stock
Out of Stock
Lead Time To Ship May Vary
Price:
$169.74
$130.57
Switches isolated battery banks to all loads or combines battery banks to all loads
Includes AFD (Alternator Field Disconnect)
Make-before-break contact design allows switching between battery banks without power interruption
Ignition protected - safe for installation aboard gasoline powered boats
Case design allows surface or rear panel mounting
Accepts two 4/0 AWG (95mm2) battery cables
Instructions
Mounting Diagram
Specifications
Switch Type
Selector 4 Position
Color
Grey
Switch Positions
4
Battery Combine
Yes
Alternator Field Disconnect
Yes
Maximum Voltage
32V DC
Terminal Stud Torque
220 in-lb (24.86 Nm)
Continuous Rating
500A
Intermittent Rating
700A (5 min)
Cranking Rating 30 sec
1600A
Battery Inputs
2
Cable Clearance For 4/0 AWG Cables
1.10in (27.94 mm)
Cable Quantity to Meet Ratings
Two Cables / Terminal
Cable Size to Meet Ratings
4/0 AWG (120mm2)
Mounting Holes
Accept 1/4" (M6) Screw
Terminal Stud Size
1/2" (M12)
Weight
1.25lb (0.57 kg)
