Blue Sea Systems, 7606, 20A BatteryLink Charger - Bare Wire (Universal)

Model: 7606
GTIN: 00632085076061
Manufactured by: Blue Sea Systems
Condition: New
Estimated Delivery: May 3rd - May 9th
Estimated Delivery: 1 to 2 Weeks
In Stock
Out of Stock
Lead Time To Ship May Vary

Price:

$539.61 $415.09

Manufacturer Info

Other products

Charge two batteries at or away from the dock with a 20A multistage battery charger and integrated 170A Automatic Charging Relay (ACR)

AC charging at the dock: Use AC shore power to charge two isolated battery banks with the 3 Stage 20 Amp battery charger
DC charging away from the dock: Share the DC power from the alternator with both the Start and the Auxiliary battery through the integrated 170A ACR
Battery Temperature Compensation prolongs battery life
Start isolation protects sensitive electronics from voltage sags and spikes
Emergency parallel allows remote ability to jump start by combining both batteries if start battery is low
Includes LED remote indicator for charge status at the helm
Snap-on insulating cover
One-piece stainless flange nuts ensure safe and secure connections

Total Output Current	20A
Nominal Voltage	12V DC
Number of Outputs	1 Negative 2 Positive
Terminal Stud Torque	60 in-lb (6.78 Nm)
Continuous Rating	170A
Universal AC Input Voltage	90-265V AC
AC Input Frequency	50/60Hz
Typical Float Voltage	13.5V DC
Battery Types	AGM Flooded TPPL
Cable Size to Meet Ratings	10 AWG Negatve Cable 6 AWG Positive cable
Maximum Battery CCA	850CCA
Maximum Cable Size	1/0 AWG (50mm)
Operating Current	10mA 60mA
Plug Style	Bare Wire
Recommended Battery Bank Sizes	60Ah Minumum
Terminal Stud Size	1/4"-20
Warranty	5 Year
Combine 30 sec	13.5V
Combine 2 Min	13.0V
Open 10 sec	12.35V
Open 30 sec	12.75V
