Blue Sea Systems, 7531, P12 Battery Charger - 12V DC 25A Blue Sea Systems, 7531, P12 Battery Charger - 12V DC 25A
Blue Sea Systems, 7531, P12 Battery Charger - 12V DC 25A
The images shown are for illustration purposes only and may not be an exact representation of the product

Blue Sea Systems, 7531, P12 Battery Charger - 12V DC 25A

  • Model: 7531
  • GTIN: 00632085075316
  • Manufactured by: Blue Sea Systems
  • Condition: New
  • Estimated Delivery: 1 to 2 Weeks
  • Lead Time To Ship May Vary
Price:

$1,003.42 $771.86

Manufacturer Info

(image for) Blue Sea Systems
Four stage, three output, dry mount design, for use in harsh environments.
  • Rugged, finned aluminum case
  • PreFloat stage prevents over charging
  • Power factor corrected for efficient use of AC
  • Intuitive diagnostic screens
  • User defined charge profiles and customizable settings
  • Provides charging for up to three battery banks
  • Large, bright display
  • Multi-language: English, French, German, Italian, Spanish
  • Charge Coordination with Blue Sea Systems Automatic Charging Relays (ACR) controls ACR state ensuring proper float stage for each battery
  • Battery Temperature Compensation - adjusts charge voltage based on battery temperature
  • AC over and under voltage shut down and automatic restart
  • Over and under battery temperature protection - charger will not operate if battery temperature riSea above or falls below a set value
  • DC over voltage and reverse polarity protection
  • Surge and short circuit protection
  • MSDS: NYOGEL 760G
  • Instructions
  • Dimensioned Drawing
  • P12 Remote Instructions
Total Output Current 25A
Input AC Current 4.5A @ 100V AC 2.25A @ 200V AC
Maximum Output Voltage 16V DC
Nominal Voltage 12V DC
Ignition Protected Yes
Number of Outputs 1 negative 3 positive
Universal AC Input Voltage 115-230V AC
AC Input Frequency 45-65Hz
Output Voltage Accuracy 0.05V
Typical Float Voltage 13.5V DC
Minimum Operating Temperature -20 C
Maximum Operating Temperature 70 C
Minimum Storage Temperature -30 C
Maximum Storage Temperature 80 C
Battery Types AGM Flooded Lead Acid Gel TPPL (Thin Plate Pure Lead)
Recommended for Battery Bank Sizes 330Ah Maximum 60Ah Minimum
Warranty 5 Year
Height 13.03in (330.96 mm)
Width 8.46in (214.88 mm)
Depth 3.66in (92.96 mm)
Weight 13.00lb (5.9 kg)
