AIMS Power, PIC100012120S, 1000W Pure Sine Inverter Charger 25/55A
The images shown are for illustration purposes only and may not be an exact representation of the product

AIMS Power, PIC100012120S, 1000W Pure Sine Inverter Charger 25/55A

  • Model: PIC100012120S
  • GTIN: 00840271003160
  • Manufactured by: AIMS Power
  • Condition: New
  • This product is currently on backorder.
    Expected Ship Date: Saturday 31 May, 2025
Price:

$592.02 $455.40

Manufacturer Info

(image for) AIMS Power
Features
  • 1000 Watt continuous power
  • 2000 Watt surge
  • Selectable 25A or 55A Battery Charger
  • Built in Transfer Switch
  • 12 Volt DC input
  • Pure sine wave
  • Conformal Coated Circuit Board
  • AC Direct Connect Terminal Block
  • Efficiency: 86% - 90%
  • Over load and Short circuit protection
  • On/off switch
  • Dual cooling fans thermally controlled
  • Instruction manual
  • 1 year tech support
  • 1 Year Warranty Parts and Labor replacement
  • Optional Remote Switch Available (Part# REMOTEHF)
Specifications
  • Continuous output power: 1000 Watts
  • Surge power capability (peak power): 2000 Watts
  • Battery Charge Current 25A or 55A (optional)
  • AC/Inverter Transfer Time: 20ms
  • DC input / operating voltage: 10-16 Volts
  • AC Input Voltage Range: 120 Volts AC +/- 10%
  • Output voltage: 120 Volts AC
  • Output frequency: 60 Hz
  • Output wave form: pure sine wave (THD 3%)
  • Over voltage shutdown: 16 +/- 0.5 Volts
  • Battery low voltage alarm: 9.8 +/- 0.3 Volts
  • Battery low voltage shutdown: 9.5 +/- 0.5 Volts
  • Battery Overcharge Protection Voltage: 14.4 Volts
  • Battery Float Charge Voltage: 13.5 Volts
  • Efficiency Range: 86% - 90%
  • No Load Current: 1.2A
  • No load minimum operating temperature: 32 degrees Fahrenheit
  • Unit weight 12.1 LBS
  • Shipping weight 15lbs
  • Unit dimensions 17 1/4"x9 1/4"x4"
