Solis-(75-100)K-5G-US - AC-SPRT (SunSpec MLRSD Transmitter)
- AC-RSS (Tigo MLRSD Transmitter)
- AC-PID (Potential Induced Degradation)
Ordering guidelines: Determine the basic model from above and add your desired features as described
Ex: Solis-75K-5G-US-AC-SPRT, (inverter internal Sunspec transmitter)75-100kW three phase series string inverter have Maximum 28 strings input, support "Y" type connection in DC side. Maximum string input current 13A, support bifacial modules access.Supports anti-PID function to improve system eff iciency. High-precision intelligent strings monitoring reduces fault location time
75-100kW Three Phase InverterLeading Features - > 150% DC/AC ratio
- Night SVG function
- Compatible with bifacial modules
- 8/9/10 MPPTs, max. efficiency 98.8% (CEC efficiency 98.3%)
- Intelligent string monitoring, smart I-V curve scan
- IP66
- CA Rule 21 compliant and UL 1741 SA Certified
- Built-in PID recovery for better module performance
- Globally recognised branded componentry for longer life
- DC side supports "Y" connector
- Support aluminium wire to reduce cost
- Remote firmware upgrade with simple operation (Requires the user to use Solis monitoring5)
- Datasheet_Solis-(75-100)K-5G-US.pdf | Download
- Solis_Manual_75_100K_5G_USA_V1.4.pdf | Download
- APS_certificate_UL 1741_RHI-1P(5-10)K-HVES-5G_(75-100)K-US_US_V01.pdf | Download
- Solis_certificate_IEEE 1547&UL 1741&UL 1699B&C22.2_(75-100)K-5G-US_US_V01.pdf | Download
- Solis_certificate_IEEE 1547&UL 1741&UL 1699B&C22.2_(75-100)K-5G-US_US_V03.pdf | Download
